The FUJI ELECTRIC VFC400P-5T is a regenerative blower — a ring compressor — rated for 1 hp output at 115/230V AC single-phase, 60 Hz. It delivers a maximum flow of 98 cfm and a maximum vacuum of 50 in wc, with a maximum operating pressure of 54.3 in wc. The motor carries Class B NEMA insulation and includes automatic-reset thermal protection.
FUJI ELECTRIC VFC400P-5T Regenerative Blower, 1 hp, 115/230V
MPNVFC400P-5T
FUJI ELECTRIC regenerative blower, VFC400P-5T, 1 hp, 115/230V AC single-phase, 60 Hz, 98 cfm max flow, 50 in wc max vacuum, Class B NEMA insulation.
$991.73 – $1,676.30Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Product type | Ring Compressor |
| Parameter | Value |
|---|---|
| Max. flow rate | 98 cfm |
| Max. operating pressure | 54.3 in wc |
| Max. vacuum | 50 in wc |
| Parameter | Value |
|---|---|
| Output power | 1 hp |
| Voltage | 115/230V AC |
| Phase | Single |
| Frequency | 60 Hz |
| Current rating | 8.6/4.3 A |
| Thermal protection | Automatic Reset |
| Standards | Class B NEMA Insulation |
| Parameter | Value |
|---|---|
| Inlet size | 1-1/2 in |
| Outlet size | 1-1/2 in |
| Inlet type | NPT |
| Outlet type | NPT |
| Inlet connection gender | Female |
| Outlet connection gender | Female |
| Housing material | Aluminum |
| Overall length | 12.18 in |
| Overall height | 11.93 in |
| Overall depth | 11.62 in |
| Weight | 51 lb |
| Parameter | Value |
|---|---|
| Ambient temperature, max. | 104 °F |
| Max. air temperature rise | 119 °F |
Product details
Frequently asked questions
What is VFC400P-5T's listed item type?
It is a Ring Compressor, which is another term for a regenerative blower.
What is VFC400P-5T's listed phase?
Single phase.
MPN
VFC400P-5T
