Schneider Electric BSH140 Series
120 variants · Schneider Electric
Schneider Electric BSH140 Series — schneider
Schneider Electric BSH140 Series includes 120 variants for industrial automation. Standardized form factors for DIN rail/panel mounting in motor control centers, distribution boards, and PLC I/O systems.
Applications
Control panels, machine building, building services.
Selection
Match rated current, voltage, poles, and control voltage. Provide complete order code for pricing and availability.
Availability
Standard configurations in distributor inventory.
About the Schneider Electric BSH140 Series
The Schneider Electric BSH140 Series series groups 120 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common main product or component type of Servo motor and max axial force fa n of 0.2 x Fr. Variants differ by centring collar diameter, feedback type and frequency, so you can match the exact centring collar diameter your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Schneider Electric BSH140 Series variants and discontinued ones from a single page.
Select a variant by
- Centring collar diameter
- 5.1 in (130 mm) · 130 mm
- Feedback type
- Multiturn SinCos Hiperface · Single turn SinCos Hiperface
- Frequency
- 4 kHz · 8 kHz
- IP rating
- IP50 · IP65 / IP67
- Length
- 8.6 in (217.5 mm) · 12.2 in (310.5 mm) · 15.06 in (382.5 mm) · 217.5 mm · 272.5 mm · 310.5 mm
- Max radial force fr n
- 1530 N 3000 rpm 1760 N 2000 rpm 2210 N 1000 rpm · 1530 N at 3000 rpm 1760 N at 2000 rpm 2210 N at 1000 rpm · 1680 N 3000 rpm 1930 N 2000 rpm 2430 N 1000 rpm · 1680 N at 3000 rpm 1930 N at 2000 rpm 2430 N at 1000 rpm · 1840 N 3000 rpm 2110 N 2000 rpm 2660 N 1000 rpm
- Shaft diameter
- 0.9 in (24 mm) · 24 mm
- Shaft end type
- Keyed · Untapped
Shared specifications
- Main product or component type
- Servo motor
- Max axial force fa n
- 0.2 x Fr
Variant comparison
| Parameter | BSH1402T22F2P | BSH1401P31A1A | BSH1402P21A1A | BSH1402P01F2A | BSH1401T22A2A | BSH1402P01A2A |
|---|---|---|---|---|---|---|
| Centring collar diameter | 5.1 in (130 mm) | 5.1 in (130 mm) | 130 mm | 130 mm | 130 mm | 130 mm |
| Feedback type | Multiturn SinCos Hiperface | Single turn SinCos Hiperface | Single turn SinCos Hiperface | Single turn SinCos Hiperface | Multiturn SinCos Hiperface | Single turn SinCos Hiperface |
| Frequency | 8 kHz | 8 kHz | 4 kHz | 4 kHz | 4 kHz | 4 kHz |
| IP rating | IP65 / IP67 | IP65 / IP67 | IP65 / IP67 | IP50 | IP65 / IP67 | IP50 |
| Length | 12.2 in (310.5 mm) | 8.6 in (217.5 mm) | 272.5 mm | 310.5 mm | 217.5 mm | 272.5 mm |
| Max radial force fr n | 1680 N 3000 rpm 1930 N 2000 rpm 2430 N 1000 rpm | 1530 N 3000 rpm 1760 N 2000 rpm 2210 N 1000 rpm | 1680 N at 3000 rpm 1930 N at 2000 rpm 2430 N at 1000 rpm | 1680 N at 3000 rpm 1930 N at 2000 rpm 2430 N at 1000 rpm | 1530 N at 3000 rpm 1760 N at 2000 rpm 2210 N at 1000 rpm | 1680 N at 3000 rpm 1930 N at 2000 rpm 2430 N at 1000 rpm |
| Shaft diameter | 0.9 in (24 mm) | 0.9 in (24 mm) | 24 mm | 24 mm | 24 mm | 24 mm |
| Shaft end type | Untapped | Keyed | Untapped | Untapped | Untapped | Untapped |
Request a quote on any Schneider Electric BSH140 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
