GS2K4
Schneider Electric
80 °C-40 °C10–25 kA
Ref. price$334.58
Lead time on requestGet quote
Schneider Electric GS2K Contactors Series
6 variants · Schneider Electric
About the Schneider Electric GS2K Contactors Series
The Schneider Electric GS2K Contactors Series series groups 6 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common breaking capacity of 10000 A at 400 V (AC-23B), electrical life cycles of 1000 cycles AC-23 A 1000 cycles DC-23 A 200 cycles AC-23B 200 cycles DC-23B and height of 162 mm. Variants differ by depth, fuse type and width, so you can match the exact depth your application requires using the selection guide below.
Select a variant by
- Depth
- 116 mm · 126.5 mm
- Fuse type
- DIN · NFC
- Width
- 148 mm · 184 mm
Shared specifications
- Breaking capacity
- 10000 A at 400 V (AC-23B)
- Electrical life cycles
- 1000 cycles AC-23 A 1000 cycles DC-23 A 200 cycles AC-23B 200 cycles DC-23B
- Height
- 162 mm
- Main product or component type
- Switch-disconnector-fuse
- Mechanical life cycles
- 10000 cycles
- Operating temperature
- -20...70 °C
- Storage temperature
- -40...80 °C
- Temp operating max
- 70 °C
- Temp operating min
- -20 °C
- Temp storage max
- 80 °C
- Temp storage min
- -40 °C
Variant comparison
| Parameter | GS2K4 | GS2KG3 | GS2KKG3 |
|---|---|---|---|
| Depth | 116 mm | 116 mm | 126.5 mm |
| Fuse type | NFC | NFC | DIN |
| Width | 184 mm | 148 mm | 148 mm |
Request a quote on any Schneider Electric GS2K Contactors Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
