Schneider Electric TM22 Series

10 variants · Schneider Electric

About the Schneider Electric TM22 Series

AO Ctrl is a China industrial automation distributor and independent sourcing agent for Schneider Electric TM22 Series components — the parts repair and maintenance teams source here when a machine is down or the line is no longer sold locally — with the physical condition of every unit stated up front. The Schneider Electric TM22 Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common backup time of 1 year 77 °F (25 °C) by interruption of power supply), battery type of BR2032 or CR2032X lithium non-rechargeable and depth of 2.8 in (70 mm). Variants differ by mechanical life cycles, reset time and input impedance, so you can match the exact mechanical life cycles your application requires using the selection guide below. All listed Schneider Electric TM22 Series part numbers are active and orderable.

Select a variant by

Mechanical life cycles: 20000000 cycles for transistor output · 20000000 cycles relay output
Reset time: 1 s · 1 s automatic reset
Input impedance: 3.4 kOhm discrete input 100 kOhm analog input 4.9 kOhm fast input · 100 kOhm analog input 3.4 kOhm input 4.9 kOhm fast input
Response time: 35 µs turn-off, I2...I5 input 5 µs turn-on, I0, I1, I6, I7 fast input 35 µs turn-on, other terminals input 5 µs turn-off, I0, I1, I6, I7 fast input 100 µs turn-off, other terminals input 5 µs turn-on, turn-off, Q0...Q1 output 50 µs turn-on, turn-off, Q2...Q3 output 300 µs turn-on, turn-off, other terminals output · 35 µs turn-off, I2...I5 input 10 ms turn-on output 10 ms turn-off output 5 µs turn-on, I0, I1, I6, I7 fast input 35 µs turn-on, other terminals input 5 µs turn-off, I0, I1, I6, I7 fast input 100 µs turn-off, other terminals input

Shared specifications

Backup time: 1 year 77 °F (25 °C) by interruption of power supply)
Battery type: BR2032 or CR2032X lithium non-rechargeable
Depth: 2.8 in (70 mm)
Discrete input logic: Sink or source (positive/negative)
Height: 3.5 in (90 mm)
IP rating: IP20
Main product or component type: Logic controller
Operating temperature: 14...131 °F (-10...55 °C) horizontal installation) 14...95 °F (-10...35 °C) vertical installation)
Pollution degree: <= 2
Storage temperature: -13...158 °F (-25...70 °C)
Temp operating max: 55 °C
Temp operating min: -10 °C

Variant comparison

Parameter	TM221ME32TK	TM221ME16R	TM221M32TK	TM221ME16RG	TM221ME16T	TM221ME16TG
Mechanical life cycles	20000000 cycles for transistor output	20000000 cycles relay output	20000000 cycles for transistor output	20000000 cycles relay output	20000000 cycles for transistor output	20000000 cycles for transistor output
Reset time	1 s automatic reset	1 s	1 s automatic reset	1 s	1 s automatic reset	1 s automatic reset
Input impedance	—	100 kOhm analog input 3.4 kOhm input 4.9 kOhm fast input	3.4 kOhm discrete input 100 kOhm analog input 4.9 kOhm fast input	100 kOhm analog input 3.4 kOhm input 4.9 kOhm fast input	—	100 kOhm analog input 3.4 kOhm input 4.9 kOhm fast input
Response time	—	35 µs turn-off, I2...I5 input 5 µs turn-on, I0, I1, I6, I7 fast input 35 µs turn-on, other terminals input 5 µs turn-off, I0, I1, I6, I7 fast input 100 µs turn-off, other terminals input 5 µs turn-on, turn-off, Q0...Q1 output 50 µs turn-on, turn-off, Q2...Q3 output 300 µs turn-on, turn-off, other terminals output	35 µs turn-off, I2...I5 input 5 µs turn-on, I0, I1, I6, I7 fast input 35 µs turn-on, other terminals input 5 µs turn-off, I0, I1, I6, I7 fast input 100 µs turn-off, other terminals input 5 µs turn-on, turn-off, Q0...Q1 output 50 µs turn-on, turn-off, Q2...Q3 output 300 µs turn-on, turn-off, other terminals output	35 µs turn-off, I2...I5 input 5 µs turn-on, I0, I1, I6, I7 fast input 35 µs turn-on, other terminals input 5 µs turn-off, I0, I1, I6, I7 fast input 100 µs turn-off, other terminals input 5 µs turn-on, turn-off, Q0...Q1 output 50 µs turn-on, turn-off, Q2...Q3 output 300 µs turn-on, turn-off, other terminals output	—	35 µs turn-off, I2...I5 input 5 µs turn-on, I0, I1, I6, I7 fast input 35 µs turn-on, other terminals input 5 µs turn-off, I0, I1, I6, I7 fast input 100 µs turn-off, other terminals input 5 µs turn-on, turn-off, Q0...Q1 output 50 µs turn-on, turn-off, Q2...Q3 output 300 µs turn-on, turn-off, other terminals output

Request a quote on any Schneider Electric TM22 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
