SICK GTB6-P4212 — Proximity Sensors

GTB6-P4212 Photoelectric Proximity Sensor, PNP, 250 mm, IP67

MPNGTB6-P4212

SICK G6 series miniature photoelectric proximity sensor, PNP, 250 mm sensing range, 625 µs response, 10–30 VDC, 100 mA load, M8 4-pin connector, IP67, GTB6-P4212.

$99.06 – $173.52Ref. price · indicative, final on quote
SICK GTB6-P4212 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

GTB6-P4212 — Identification
ParameterValue
SeriesG6
GTB6-P4212 — Sensing
ParameterValue
Sensing distance, max.250 mm
GTB6-P4212 — Electrical
ParameterValue
Operating voltage, max.30 VDC
Operating voltage, min.10 VDC
Termination typeConnector, M8, 4-Pin
GTB6-P4212 — Output
ParameterValue
Load current100 mA
GTB6-P4212 — Mechanical
ParameterValue
Length32 mm
GTB6-P4212 — Environmental
ParameterValue
Operating temperature, max.55 °C
Operating temperature, min.-25 °C
IP protection ratingIP67

Product details

The GTB6-P4212 is a G6-series miniature photoelectric proximity sensor with a 250 mm sensing range and a 625 µs response time — fast enough to catch parts on a moderate-speed conveyor or detect presence in a pick-and-place cell without missing targets. The PNP output switches 100 mA, so it drives a standard PLC input directly; no interposing relay needed. Light-ON / Dark-ON switching is selectable, which means one part covers both diffuse and retro-reflective logic without a separate variant. The 12 mm wide housing fits tight DIN-rail or machine-mount slots, and the M8 4-pin connector simplifies field replacement — unplug the old sensor, plug in the new one, no rewiring.

Deployment context

Rated IP67, so the sensor body and optics handle washdown and dust — suitable for packaging lines, bottling plants, or any area where a hose-down cleaning cycle is routine. The 10–30 VDC supply range covers standard 24 VDC control power with headroom for brownout conditions.

Frequently asked questions

What is the closest functional second-source for GTB6-P4212?

The GTB6-P4231 is the closest peer in the G6 family: same 12 mm width, same M8 4-pin connector, same PNP output and 100 mA load rating. The main difference is the P4231 has a longer 400 mm sensing range and a 1.2 ms response time (slower than the P4212's 625 µs). If your application needs the faster response, the P4212 is the right call; if range matters more, the P4231 is a direct swap on the same mounting footprint.

Where can I buy GTB6-P4212?

The GTB6-P4212 is sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing are confirmed at quote time.

Will GTB6-P4212 drop into a panel specified around GTB6-P4231 without rewiring?

Yes — both sensors share the same 12 mm width, M8 4-pin connector, PNP output, and 10–30 VDC supply. The wiring pinout is identical, so the P4212 replaces the P4231 without changing the cable or terminal assignment. The only functional difference is the sensing range (250 mm vs 400 mm) and response time (625 µs vs 1.2 ms).

MPN
GTB6-P4212
