The OD2-P120W60C0 is a 2D laser displacement sensor from the OD Value series, delivering a PNP output over a 60.0 mm to 180.0 mm installation distance. It runs on a 12 ~ 24VDC supply and is terminated via a connector — no pigtails to dress. The IP67 rating means the housing and optics survive washdown on a packaging or food line; the sensor body is chassis-mounted, so you bolt it to a bracket or machine frame, not a DIN rail.
The 60.0 mm to 180.0 mm installation distance defines the standoff range where the sensor produces a valid 2D profile. At 120 mm center distance it gives ±60 mm measurement width — that is the working window for checking part height, gap, or contour on a moving line. The PNP output (sourcing) is standard for PLC inputs that expect a positive signal; verify your input card sinks or sources accordingly. IP67 means the sensor body is dust-tight and protected against temporary immersion — fine for washdown zones but not continuous submersion.
