The OD2-P250W150U2 is a 2D laser displacement sensor from the SICK OD Value series, delivering a PNP discrete output. It operates on a 12 to 24 VDC supply and covers an installation distance range of 100.0 mm to 400.0 mm. Rated IP67, the sensor body and optics handle washdown environments — suitable for food-and-bev lines or outdoor installations where dust and water jets are present. The operating temperature span of -10°C to 40°C covers most indoor factory-floor conditions, though you'll want to keep it out of direct oven heat or freezer zones.
Integration notes
Chassis-mount form factor with cable leads for termination — plan for a cable gland or strain relief at the panel entry point. The IP67 rating holds as long as the cable entry is sealed. The 100.0 mm to 400.0 mm installation distance is the working range for the 2D profile measurement; the sensor must be mounted within that gap from the target surface. Outside that band, the laser spot defocuses and measurement accuracy drops off.
