2D Laser Displacement Sensor — OD2-P50W10C0
The OD2-P50W10C0 is a 2D laser displacement sensor from the OD Value series, delivering a 50mm measurement range with ±10mm linearity in a PNP output format. It operates on a 12~24VDC supply and is chassis-mounted with a connector termination — ready for integration into automated inspection or positioning systems where a single sensor profiles surface height or edge position. The 40.0mm to 60.0mm installation distance gives you a flexible standoff window for mounting over conveyors or part fixtures without precision shimming. Operating temperature spans -10°C to 40°C, which covers most factory-floor conditions but not freezer or high-heat zones. If your line runs above 40°C ambient, you'll need to relocate the sensor or add local cooling.
Peer Variant — OD2-P50W10A0
The closest functional sibling is the OD2-P50W10A0, which shares the same 2D laser displacement sensor type, OD Value series, chassis mount, 12~24VDC supply, connector termination, IP67 ingress protection, 40.0mm~60.0mm installation distance, and -10°C~40°C operating temperature. The only difference is the output type — the C0 variant is PNP, while the A0 variant is analog output. If your control input expects a 4-20mA or 0-10V signal, the A0 is the correct choice; for a PLC digital input or PNP-compatible controller, the C0 drops in without rewiring.
Integration Notes
Chassis mount with connector termination — no flying leads to strip. The IP67 seal is intact as long as the mating connector is also rated IP67. Mount within the 40.0mm~60.0mm standoff range; the sensor's optics are factory-calibrated for that window, so deviating outside it degrades measurement accuracy.
