The 3RA2110-1GA15-1AP6: This is a non-fused motor starter in the SIRIUS series, size S00 — a direct starter design that combines a contactor and a thermal bimetallic overload relay in one unit, pre-matched and ready to wire. Rated for AC-3 duty up to 690 V, it covers 200–600 V systems commonly found in North American and European panels; motor power ranges from 0.25 hp at 110/120 V up to 5 hp at 575/600 V.
Mounting and panel integration
Vertical mounting position only; the unit is 167.2 mm tall, so allow 20 mm clearance above and 10 mm below for air circulation and wiring access.
Supplied components — what is in the box
The starter ships with a 3RT2015-1AP61 contactor and a 3RA1921-1DA00 link module pre-assembled — no separate ordering or matching required for the contactor and overload. This saves a BOM line and eliminates the risk of mismatched contactor/overload combinations during panel build or MRO replacement.
