Siemens 3RA2315-8XB30-2BB4 — Motor Starters

Siemens 3RA2315-8XB30-2BB4 SIRIUS Reversing Contactor

MPN3RA2315-8XB30-2BB4
Active

Siemens SIRIUS 3RA2315-8XB30-2BB4 reversing contactor assembly, size S00, 3 kW at 400 V AC-3, spring-loaded terminals, screw and snap-on 35 mm DIN rail mounting.

$58.42Ref. price · indicative, final on quote
Siemens 3RA2315-8XB30-2BB4 datasheet (PDF)
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

Identification

3RA2315-8XB30-2BB4 — Identification
ParameterValue
Product designationReversing contactor assembly
Main circuit poles3
BrandSIRIUS
Reference designation (IEC 81346-2)Q

Ratings & Performance

3RA2315-8XB30-2BB4 — Ratings & Performance
ParameterValue
Rated motor power at 400 V3 kW
Rated voltage at AC-3, max.690 V
Rated motor power at 460/480 V (hp)3 hp
Rated motor power at 575/600 V (hp)5 hp
Rated current at 480 V4.8 A
Rated current at 600 V6.1 A

Contacts & Control

3RA2315-8XB30-2BB4 — Contacts & Control
ParameterValue
Control supply voltage typeDC
Auxiliary switch extensionYes

Communication

3RA2315-8XB30-2BB4 — Communication
ParameterValue
AS-Interface protocol supportNo

Mechanical & Connection

3RA2315-8XB30-2BB4 — Mechanical & Connection
ParameterValue
Mounting / fastening methodscrew and snap-on mounting onto 35 mm DIN rail
Mounting position+/-180° rotation possible on vertical mounting surface; can be tilted forward and backward by +/- 22.5° on vertical mounting surface
Width90 mm
Height84 mm
Depth83 mm

Environmental

3RA2315-8XB30-2BB4 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C

Product details

Reversing contactor assembly, size S00

The Siemens 3RA2315-8XB30-2BB4 is a SIRIUS reversing contactor assembly built from two 3RT2015-2BB42 contactors on a common mounting plate, wired for forward/reverse motor control. Size S00 keeps the footprint tight — 90 mm wide, 84 mm tall, 83 mm deep — so it wires up clean in a crowded panel without hogging DIN rail.

Duty ratings and terminal work

Current draw at 480 V is 4.8 A; at 600 V it pulls 6.1 A. The magnet coil also terminates on spring-type terminals, same wire range. Clearance around the assembly: 6 mm upward, forward, downward, and to the side; zero clearance needed backward.

Frequently asked questions

How can I order 3RA2315-8XB30-2BB4 or request a quote?

Sourced through Siemens authorized distribution. No stock-holding claim — quoted per order.
