Overview
The 3RA2324-8XE30-1BB4 is a Siemens Unclassified device with 3 poles, rated 690 V AC and 5.9 W, housed in an IP20 enclosure for screw or snap-on mounting onto a 35 mm standard mounting rail. Siemens has discontinued this part.
Siemens 3RA2324-8XE30-1BB4 Unclassified, 3-pole, 690 V, 5.9 W
MPN3RA2324-8XE30-1BB4
NRND
Siemens 3RA2324-8XE30-1BB4 — now in phase-out and being discontinued. Supplied from remaining channel stock; full specifications, lifecycle and same-series options are below.
$120.65Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Product designation | Reversing contactor assembly |
| Main circuit poles | 3 |
| Brand | SIRIUS |
| Reference designation (IEC 81346-2) | Q |
Ratings & Performance
| Parameter | Value |
|---|---|
| Rated motor power at 400 V | 5.5 kW |
| Rated motor power at 460/480 V (hp) | 7.5 hp |
| Rated motor power at 575/600 V (hp) | 10 hp |
| Rated current at 480 V | 11 A |
| Rated current at 600 V | 11 A |
Contacts & Control
| Parameter | Value |
|---|---|
| Control supply voltage type | DC |
| Auxiliary switch extension | Yes |
Communication
| Parameter | Value |
|---|---|
| AS-Interface protocol support | No |
Mechanical & Connection
| Parameter | Value |
|---|---|
| Main contact conductor range (AWG) | 2x (16 ... 12), 2x (14 ... 8) |
| Mounting / fastening method | screw and snap-on mounting onto 35 mm standard mounting rail |
| Mounting position | +/-180° rotation possible on vertical mounting surface; can be tilted forward and backward by +/- 22.5° on vertical mounting surface |
| Width | 90 mm |
| Height | 101 mm |
| Depth | 107 mm |
Environmental
| Parameter | Value |
|---|---|
| Operating temperature range | -25 ... +60 °C |
| Storage temperature range | -55 ... +80 °C |
Product details
MPN
3RA2324-8XE30-1BB4
