Reversing starter for motor control panels — 15 kW at 400 V
The 3RA6250-1EB33: The adjustable trip class (CLASS 10 and 20) lets you match the overload protection to the motor start profile: CLASS 10 for faster-starting loads like pumps, CLASS 20 for high-inertia fans or conveyors that need a longer acceleration ramp.
Mounting and integration — DIN rail, any orientation
Snap-on or screw-fix to standard mounting rail in any position — vertical, horizontal, or flat — which gives panel builders flexibility in dense enclosures where rail orientation is constrained by other gear. The main current circuit uses a plug-in interface without terminals — the power connections are made via the matching SIRIUS bus system or direct plug-in links, not individual screw clamps.
Environmental ruggedness for machine-mount service
Rated for continuous operation per IEC 60947-6-2, with a pollution degree of 3 — suitable for industrial environments where conductive dust or humidity is present. Withstands shock at 60 m/s² (6 g) over 10 ms per three shocks in all axes, and vibration from 4 to 500 Hz at up to 20 m/s² — the unit holds up on machine-mounted panels near presses, conveyors, or compressors.
Sourcing and lifecycle — current production, quoted to order
For volume purchases or project pricing, submit an RFQ.
