Siemens 3RF3405-1BB24 — Solid State Relays

Siemens 3RF3405-1BB24 SIRIUS solid-state contactor, 3.4 A at

MPN3RF3405-1BB24
Active

Siemens SIRIUS solid-state contactor, 3RF3405-1BB24, two-phase controlled, 3.4 A at 480 V, 48-480 VAC load, 110-230 VAC control, screw terminals.

$87.63Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

3RF3405-1BB24 — Identification
ParameterValue
Product designationsolid-state contactor
3RF3405-1BB24 — Electrical
ParameterValue
Rated value at 200/208 V (hp)0.5 hp
Rated value at 220/230 V (hp)0.75 hp
Rated value at 460/480 V (hp)2 hp
3RF3405-1BB24 — Contacts & Poles
ParameterValue
Main circuit poles3
Main NO contacts (count)2
Auxiliary NO contacts (count)0
Auxiliary NC contacts (count)0
3RF3405-1BB24 — Coil
ParameterValue
Control supply voltage typeAC
3RF3405-1BB24 — Timing
ParameterValue
ON-delay time5 ms
OFF-delay time30 ms; additionally max. one half-wave
3RF3405-1BB24 — Connection & Mechanical
ParameterValue
Mounting positionvertical
Fastening / mounting methodscrew and snap-on mounting onto 35 mm DIN rail

Product details

It switches instantaneously (no zero-cross delay) with an on-delay of 5 ms and an off-delay of 30 ms plus a half-wave maximum, so it's suited for applications where timing predictability matters, like heater banks or lamp loads. The 3.4 A rating at 480 V (2 hp at 460/480 V) gives you the motor-load envelope; the 0.82 power factor and 200 A²·s I²t tell you it handles inrush without derating drama.

Vertical mounting position only. Screw terminals on the main circuit accept 1.5–6 mm² stranded or 1x 0.5–2.5 mm² / 2x 0.5–1.0 mm² solid. Control supply is 110–230 V AC at 2 mA — that's a low burden on the PLC output or relay driving it.

Frequently asked questions

What are the key electrical ratings for this contactor?

Load voltage 48–480 V AC at 50/60 Hz, rated operational current 3.4 A at 480 V, control supply 110–230 V AC drawing 2 mA. Horsepower equivalents: 0.5 hp at 200/208 V, 0.75 hp at 220/230 V, 2 hp at 460/480 V. Minimum operational current is 100 mA.

What clearance do I need around this contactor in the panel?

Above the unit allow 70 mm upwards clearance; below allow 50 mm downwards. The main contacts need 7 mm air clearance. These are minimums for airflow and arc containment.

What wire sizes does the screw terminal accept?

Solid: 1x 0.5–2.5 mm² or 2x 0.5–1.0 mm². Stranded: 1.5–6 mm². Use ferrules for stranded below 1.5 mm².

What are the storage and operating temperature limits?

Operating: -25 to +60 °C. Storage: -55 to +80 °C. The rated current is valid up to 40 °C; derate above that per the manufacturer's curve.

MPN
3RF3405-1BB24
