The 3RG40 22-3KB00: The Siemens 3RG4022-3KB00 is an inductive sensor in a cylindrical M12 housing, offering a 4 mm sensing range and a normally open switching output. It operates on a supply voltage of 20 to 265 V AC/DC and switches up to 200 mA via its M12 connector.
3RG40 22-3KB00 Siemens Inductive Sensor M12 4mm EOL
MPN3RG40 22-3KB00
End of Life
Siemens 3RG4022-3KB00 inductive sensor, M12 cylindrical, 4 mm sensing range, 200 mA, 20-265 V AC/DC.
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Type | Inductive Sensor |
Output
| Parameter | Value |
|---|---|
| Switching output | Normally open |
Mechanical
| Parameter | Value |
|---|---|
| Housing material | Nickel-plated brass |
Other specifications
| Parameter | Value |
|---|---|
| Model | 3RG4022-3KB00 |
| Weight | 0,04 kg |
| Housing | Cylindrical |
| Condition | New |
| Shelf no. | 240605 |
| Dimensions | M12 Diameter |
| Sensing distance | 4 mm |
| Connector type | M12 Connector |
| Current rating | 200 mA |
| Type of product | Inductive Sensor |
| Operating voltage | 20…265 V AC /DC |
Product details
Frequently asked questions
What type of sensor is it?
It is an inductive sensor.
MPN
3RG40 22-3KB00
