Siemens 3RG46 21-7AG02 cylindrical inductive sensor, M8 housing, 6 mm sensing range, PNP normally open, 200 mA output, 10-30 V DC supply, nickel-plated brass, M8 3-pin connector.
Siemens 3RG46 21-7AG02 Inductive Sensor, 6 mm PNP
MPN3RG46 21-7AG02
End of Life
Siemens 3RG46 21-7AG02 cylindrical inductive sensor, M8 housing, 6 mm sensing range, PNP normally open, 200 mA output, 10-30 V DC supply, nickel-plated brass, M8 3-pin connector.
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Type | Inductive Sensor |
Output
| Parameter | Value |
|---|---|
| Switching output | Normally open |
Mechanical
| Parameter | Value |
|---|---|
| Housing material | Nickel-plated brass |
Other specifications
| Parameter | Value |
|---|---|
| Model | 3RG46 21-7AG02 |
| Weight | 0,02 kg |
| Housing | Cylindrical |
| Condition | New |
| Shelf no. | 230205 |
| Dimensions | M8,3-pin |
| Sensing distance | 6 mm |
| Connector type | M8 Connector |
| Current rating | 200 mA |
| Electrical design | PNP |
| Operating voltage | 10 … 30 V DC |
Product details
Frequently asked questions
What is the type of 3RG46 21-7AG02?
It is an inductive sensor.
What are the key ratings?
Sensing range 6 mm, PNP normally open output, 200 mA, 10-30 V DC supply, M8 cylindrical nickel-plated brass housing, M8 3-pin connector.
MPN
3RG46 21-7AG02
