Rated 10 A in AC-12 duty at 24 V, it handles resistive and solid-state loads typical of PLC outputs and relay coils. The contact arrangement is 4 normally-open instantaneous contacts — no delayed, lagging, or make-before-break switching. Size S00 means it fits the compact footprint (45 mm wide, 60 mm tall, 73 mm deep) shared with the SIRIUS 3RT contactor family, so it slots into existing panel layouts without re-spacing.
For inductive loads (contactors, solenoids), derate to the AC-15 values: 1 A at 110 V, 0.27 A at 220 V, 6 A at 230 V, 3 A at 400 V, 2 A at 500 V, 1 A at 690 V. The 4 NO contacts are rated for mechanical endurance of 30 million operations — that's the contactor body, not the contacts under load. Electrical life will be lower and depends on the switched current and voltage. Shock rated at 10g / 5 ms and 5g / 10 ms — fine for most industrial panels but not for high-vibration mobile equipment without additional damping.
Front face is IP20 — finger-safe but not washdown. Side clearance is 0 mm to adjacent devices, so it can be ganged without air gaps. Coil operates at 50/60 Hz with a rated control voltage of 24 V; the operating range is 0.8 to 1.1 times rated at 50 Hz and 0.85 to 1.1 times at 60 Hz.
It is the standard auxiliary contactor in the SIRIUS S00 frame, so any replacement would need to match the 4 NO configuration and the 10 A AC-12 rating.
