Active production — what it means for your BOM line
The 3RH2131-1AV00: RoHS compliance is documented with a substance prohibitance date of 10/01/2009, covering the EU RoHS directive scope.
Rated current across the voltage range — where it fits
The 3 instantaneous contacts handle the switching — no time-delay auxiliary contacts on this variant, so it is a straight NO/NC set for signal feedback or interlocking.
Mechanical endurance and switching frequency
Mechanical endurance is 30 million operating cycles typical — this is the failure mode ceiling for the contactor mechanism itself, not the electrical life under load. Switching frequency at DC is 10,000 cycles per hour — the mechanical recovery time between operations at that rate is the limiting factor, not the coil thermal rise.
DIN rail fit and panel clearances
Clearance distances required: 10 mm upwards, forwards, and downwards from the contactor body, plus 6 mm at the side — plan the gland plate and adjacent device spacing accordingly.
Environmental ratings for industrial panels
Relative humidity minimum is 10% — no upper humidity limit stated, but the pollution degree 3 rating implies the contactor tolerates condensation cycles.
