Siemens 3RH2140-2AF00 — Contactors

Siemens 3RH2140-2AF00 SIRIUS Auxiliary Contactor, 4 NO, 24 V

MPN3RH2140-2AF00
Active

Siemens SIRIUS auxiliary contactor, 4 NO contacts, Size S00, screw and snap-on mounting onto 35 mm DIN rail.

$19.05Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RH2140-2AF00 — Identification
ParameterValue
Contactor frame sizeS00
3RH2140-2AF00 — Ratings & Performance
ParameterValue
Rated operational current, AC-12, max.10 A
Rated value @ 400 V3 A
Rated value @ 500 V2 A
Rated value @ 690 V1 A
Rated value @ 230 V10 A
Rated value @ 24 V10 A
Rated value @ 60 V4.7 A
Rated value @ 110 V3 A
Rated value @ 220 V1.2 A
3RH2140-2AF00 — Control & Coil
ParameterValue
Control supply voltage typeAC
Rated value @ 50 Hz0.8 ... 1.1
Rated value @ 50 Hz110 V
3RH2140-2AF00 — Contacts & Poles
ParameterValue
Auxiliary contact reliability1 faulty switching per 100 million (17 V, 1 mA)
3RH2140-2AF00 — Connection & Mounting
ParameterValue
Conductor cross-section, solid or stranded2x (0,5 ... 4 mm²)
Conductor cross-section, finely stranded w/ ferrule2x (0.5 ... 2.5 mm²)
Mounting methodscrew and snap-on mounting onto 35 mm standard mounting rail
3RH2140-2AF00 — Durability
ParameterValue
Durability (operating cycles, typ.)30 000 000
Durability with aux. switch block (cycles, typ.)10 000 000
3RH2140-2AF00 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C
Installation altitude, max.2 000 m
3RH2140-2AF00 — Mechanical
ParameterValue
Width45 mm
Height70 mm
Depth73 mm
3RH2140-2AF00 — Specifications
ParameterValue
At AC4 ... 15 ms

Product details

It's the part you add to a main contactor to get extra auxiliary contacts for status feedback, interlocks, or PLC inputs — not a main power switching device. That matters when you're shoehorning it into an existing panel and the rail isn't perfectly oriented.

For higher voltages the current drops off: 4.7 A at 60 V, 3 A at 110 V, 1.2 A at 220 V, and down to 0.26 A at 600 V. If you're switching a 24 VDC PLC output or a relay coil, the 10 A rating gives comfortable margin. For a 230 VAC pilot light, the 10 A at 230 V rating (AC) still covers it easily. Arcing time is 10-15 ms AC, so the contacts clear fast.

Dimensions: 45 mm wide, 70 mm high, 73 mm deep. That's fine for 1.5 mm² or 2.5 mm² control wiring; if you're paralleling two wires into one terminal (for daisy-chaining), the 4 mm² max per conductor is generous enough for most control circuits.

RoHS compliance date is October 1, 2009, so it's RoHS-compliant for the EU market. No UL or CSA mark is listed in the spec sheet, but the SIRIUS line typically carries those approvals — verify for your specific jurisdiction if UL listing is mandatory.
