Siemens 3RH2911-4DA11 — Contactors

Siemens 3RH2911-4DA11 SIRIUS Auxiliary Switch, 1 NO + 1 NC,

MPN3RH2911-4DA11

Siemens SIRIUS auxiliary switch, lateral, 1 NO + 1 NC, 10 A maximum, ring cable lug connection, for 3RT2 contactors.

$7.11Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RH2911-4DA11 — Ratings & Performance
ParameterValue
Rated value @ 24 V10 A
Rated value @ 60 V4.7 A
Rated value @ 110 V3 A
Rated value @ 220 V1.2 A
3RH2911-4DA11 — Contacts & Poles
ParameterValue
Auxiliary contact reliability1 faulty switching per 100 million (17 V, 1 mA)
3RH2911-4DA11 — Connection & Mounting
ParameterValue
Mounting methodsnap-on mounting
3RH2911-4DA11 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C
3RH2911-4DA11 — Mechanical
ParameterValue
Width10 mm
Height85.4 mm
Depth43.7 mm

Product details

The Siemens 3RH2911-4DA11 is a SIRIUS lateral auxiliary switch block designed to snap onto the left or right side of a 3RT2 contactor. It gives you one normally-open and one normally-closed instantaneous contact, with ring-tongue terminals for the control wiring. This is the add-on that lets a power contactor report its state back to a PLC or safety circuit. The contacts are rated for a maximum of 10 A, with the actual current-carrying capacity depending on the voltage and duty cycle — at 24 V it handles 6 A (AC-15), at 230 V it also handles 6 A, and at 400 V it drops to 3 A. For DC switching, the ratings are lower: 10 A at 24 V, 4.7 A at 60 V, and 0.26 A at 600 V. That matters when you're feeding a 24 VDC PLC input on a conveyor line.

The block is 10 mm wide, 85.4 mm tall, and 43.7 mm deep — it adds barely a finger's width to the contactor assembly. The front is IP00, so it lives inside an enclosure; no washdown exposure out here in the grease. Termination is via ring-tongue lugs on the control circuit. That's a field-proven connection for maintenance crews — no tiny spring-cage to fight with gloved hands. Strip, crimp, torque, and it stays put through vibration.

No official successor has been announced — this is the active design.

Frequently asked questions

What does the 'with 3RT2' note mean?

It means this auxiliary switch block is designed to mount directly onto Siemens 3RT2 series contactors. It snaps onto the left or right side and connects mechanically to the contactor's armature.

What are the key current ratings for this auxiliary switch?

The maximum rated current is 10 A. For AC-15 duty at 24 V it handles 6 A, at 230 V it handles 6 A, and at 400 V it handles 3 A. For DC switching at 24 V it handles 10 A, at 60 V it handles 4.7 A, and at 600 V it handles 0.26 A.

What type of connection does this switch use?

It uses ring-tongue lug terminals for the auxiliary and control circuit connections. This is a screw-type termination that requires a ring terminal crimped onto the wire.

What is the physical size of this auxiliary switch block?

The block is 10 mm wide, 85.4 mm high, and 43.7 mm deep. It mounts via snap-on onto a 35 mm DIN rail.

MPN
3RH2911-4DA11
