It carries a 24 VDC coil rated to hold at 10 A (AC-12) and switches motor duty at 8.5 A in AC-4 category at 400 V — the rating that governs reversing or inching applications where the contactor makes and breaks stalled-rotor current. The coil draws its rated current at 24 VDC; dropout voltage is below 18 VDC, so verify your control supply doesn't sag under load. At 45 mm wide and 72 mm deep, it fits in a standard enclosure.
Ratings and Duty Cycles
The AC-4 rating of 8.5 A at 400 V is the key figure for plugging or jogging duty — it's lower than the AC-3 rating because the contactor must interrupt locked-rotor current. For resistive loads (AC-1), the contactor is rated at 10 A. The auxiliary contacts handle 10 A at 24 V, 2 A at 60 V, 1 A at 110 V, and 0.3 A at 220 V — sufficient for signaling a PLC input or holding a smaller relay. The coil operates across 0.85...1.1 x rated voltage at 50 Hz and 0.8...1.1 at 60 Hz, giving a pickup range of roughly 20.4...26.4 VDC at 50 Hz.
The S00 footprint leaves space for an overload relay or auxiliary contact block on the same rail.
