Siemens 3RT1034-1AF04 — Contactors

Siemens 3RT1034-1AF04 SIRIUS Power Contactor, S2 Size, AC-2

MPN3RT1034-1AF04

Siemens SIRIUS power contactor, 3RT1034-1AF04, S2 size, screw-type terminals, AC-2 rated 15 kW at 400 V, 55 mm wide, snap-on DIN rail mounting.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RT1034-1AF04 — Identification
ParameterValue
Contactor frame sizeS2
3RT1034-1AF04 — Ratings & Performance
ParameterValue
Rated operational current, AC-12, max.10 A
Rated operational current, AC-4 @ 400 V29 A
Rated value @ 400 V3 A
Rated value @ 500 V18.5 kW
Rated value @ 690 V10 kW
Rated value @ 230 V6 A
Rated value @ 24 V10 A
Rated value @ 60 V2 A
Rated value @ 110 V1 A
Rated value @ 220 V0.3 A
3RT1034-1AF04 — Control & Coil
ParameterValue
Control supply voltage typeAC
Rated value @ 50 Hz0.8 ... 1.1
Rated value @ 50 Hz110 V
3RT1034-1AF04 — Contacts & Poles
ParameterValue
Main poles3
Main NO contacts3
Auxiliary contact reliability1 faulty switching per 100 million (17 V, 1 mA)
3RT1034-1AF04 — Protection & Coordination
ParameterValue
Short-circuit coordination type 1, fusefuse gL/gG: 125 A
Short-circuit coordination type 2, fusefuse gL/gG: 63 A
Aux. switch short-circuit protection, fusefuse gL/gG: 10 A
3RT1034-1AF04 — Connection & Mounting
ParameterValue
Main circuit connectionscrew-type terminals
Aux. / control circuit connectionscrew-type terminals
Conductor cross-section, solid2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²), max. 2x (0.75 ... 4 mm²)
Conductor cross-section, solid or stranded2x (0.75 ... 16 mm²)
Conductor cross-section, finely stranded w/ ferrule2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Mounting methodscrew and snap-on mounting onto 35 mm standard mounting rail according to DIN EN 50022
Side-by-side mountingYes
3RT1034-1AF04 — Durability
ParameterValue
Durability (operating cycles, typ.)10 000 000
Durability with aux. switch block (cycles, typ.)10 000 000
3RT1034-1AF04 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C
Installation altitude, max.2 000 m
3RT1034-1AF04 — Mechanical
ParameterValue
Width55 mm
Height112 mm
Depth164 mm
3RT1034-1AF04 — Specifications
ParameterValue
At AC7 ... 20 ms

Product details

The AC-4 rating of 29 A at 400 V covers inching and plugging duty, where the contactor interrupts stalled-rotor current each cycle.

The 55 mm width and 112 mm height fit standard S2 panel cutouts. Front-face protection is IP20, which keeps fingers off the terminals inside the enclosure.

Wiring and Terminal Capacity

For control wiring, the coil terminals take 2x 0.5–1.5 mm² solid or 2x 0.75–2.5 mm² stranded, with a maximum of 2x 4 mm². The power circuit can take stranded up to 25 mm² — enough for the full rated current without doubling up.

Frequently asked questions

What are the key electrical ratings for the 3RT1034-1AF04?

AC-2 motor switching at 400 V is rated at 15 kW. AC-4 inching duty at 400 V is rated at 29 A. The coil draws 10 A at 24 V and 6 A at 230 V. Mechanical life is 10,000,000 operations typical.

What compliance documentation does this brand provide for 3RT1034-1AF04?

The part is RoHS compliant with a substance prohibition date of May 1, 2012. Pollution degree 3 per IEC 60947-1 is confirmed for industrial environments.
