Siemens 3RT1044-1AL20 — Contactors

Siemens 3RT1044-1AL20 SIRIUS Power Contactor, S3, 37 kW at 5

MPN3RT1044-1AL20

Siemens SIRIUS, power contactor, 3RT1044-1AL20, S3 frame, 37 kW at 500 V AC-3, screw terminals, snap-on DIN rail.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RT1044-1AL20 — Identification
ParameterValue
Contactor frame sizeS3
3RT1044-1AL20 — Ratings & Performance
ParameterValue
Rated operational current, AC-12, max.10 A
Rated operational current, AC-4 @ 400 V55 A
Rated value @ 400 V3 A
Rated value @ 500 V37 kW
Rated value @ 690 V18.6 kW
Rated value @ 230 V6 A
Rated value @ 24 V10 A
Rated value @ 60 V2 A
Rated value @ 110 V1 A
Rated value @ 220 V0.3 A
3RT1044-1AL20 — Control & Coil
ParameterValue
Control supply voltage typeAC
Rated value @ 50 Hz0.8 ... 1.1
Rated value @ 50 Hz230 V
3RT1044-1AL20 — Contacts & Poles
ParameterValue
Main poles3
Main NO contacts3
Auxiliary contact reliability1 faulty switching per 100 million (17 V, 1 mA)
3RT1044-1AL20 — Protection & Coordination
ParameterValue
Short-circuit coordination type 1, fusefuse gL/gG: 250 A
Short-circuit coordination type 2, fusefuse gL/gG: 125 A
Aux. switch short-circuit protection, fusefuse gL/gG: 10 A
3RT1044-1AL20 — Connection & Mounting
ParameterValue
Main circuit connectionscrew-type terminals
Aux. / control circuit connectionscrew-type terminals
Conductor cross-section, solid2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²), max. 2x (0.75 ... 4 mm²)
Conductor cross-section, solid or stranded2x (2.5 ... 16 mm²)
Conductor cross-section, finely stranded w/ ferrule2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Mounting methodscrew and snap-on mounting onto 35 mm and 75 mm standard mounting rail
Side-by-side mountingYes
3RT1044-1AL20 — Durability
ParameterValue
Durability (operating cycles, typ.)10 000 000
Durability with aux. switch block (cycles, typ.)10 000 000
3RT1044-1AL20 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C
Installation altitude, max.2 000 m
3RT1044-1AL20 — Mechanical
ParameterValue
Width70 mm
Height146 mm
Depth139 mm
3RT1044-1AL20 — Specifications
ParameterValue
At AC10 ... 19 ms

Product details

It is rated 37 kW at 500 V for AC-3 duty, which is the standard category for squirrel-cage motors — so this contactor handles motor starting and running currents up to that power level without welding the main contacts during inrush.

The S3 frame footprint (146 mm height, 70 mm width) fits standard DIN-rail enclosures; its 139 mm depth clears most gland plates and back-panel wiring channels.

Solid wire accepts 2x (0.5…1.5 mm²), 2x (0.75…2.5 mm²), or max 2x (0.75…4 mm²); stranded accepts 2x (10…50 mm²). The range covers both control-circuit pilot wiring and power-circuit cable up to 50 mm² — common for a 37 kW motor feed. The terminal enclosure is IP00 (open), but the front with cover or box terminal achieves IP20, which is finger-safe for panel-side access.

Frequently asked questions

What are the key ratings for this contactor?

It is a Size S3 power contactor rated 37 kW at 500 V AC-3 for motor loads. The coil operates at 50/60 Hz with a tolerance band of 0.8…1.1 at 50 Hz and 0.85…1.1 at 60 Hz. Mechanical life is 10 million operations typical.

Will the 3RT1044-1AL20 drop into a panel specified for the 3RT1044-1FB46?

Both are S3-frame SIRIUS contactors with the same mounting footprint (146 x 70 x 139 mm) and screw terminals, so the mechanical fit and wiring are identical. The difference is in the coil voltage and auxiliary contact configuration — verify those against your control circuit before swapping.

What compliance documentation is available for this part?

The product carries IP20 front protection and is designed for pollution degree 3 environments. Specific RoHS, REACH, UL, or IEC declarations are not listed in this record but are typically available from Siemens upon request for the SIRIUS series.
