Siemens 3RT2015-1BE41 — Contactors

Siemens 3RT2015-1BE41 SIRIUS Power Contactor, S00, 24 VDC Co

MPN3RT2015-1BE41
Active

Siemens SIRIUS power contactor, size S00, 3RT2015-1BE41, 24 VDC coil, screw-type terminals, 45 x 58 x 73 mm, snap-on DIN rail mount.

$20.32Ref. price · indicative, final on quote
Siemens 3RT2015-1BE41 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RT2015-1BE41 — Identification
ParameterValue
Contactor frame sizeS00
3RT2015-1BE41 — Ratings & Performance
ParameterValue
Rated operational current, AC-12, max.10 A
Rated operational current, AC-4 @ 400 V6.5 A
Rated value @ 400 V3 A
Rated value @ 500 V2 A
Rated value @ 690 V1 A
Rated value @ 230 V0.75 hp
Rated value @ 24 V10 A
Rated value @ 60 V2 A
Rated value @ 110 V1 A
Rated value @ 220 V0.3 A
3RT2015-1BE41 — Control & Coil
ParameterValue
Control supply voltage typeDC
3RT2015-1BE41 — Contacts & Poles
ParameterValue
Main poles3
Main NO contacts3
Auxiliary contact reliability1 faulty switching per 100 million (17 V, 1 mA)
3RT2015-1BE41 — Protection & Coordination
ParameterValue
Short-circuit coordination type 1, fusegG: 35A (690V,100kA), aM: 20A (690V,100kA), BS88: 35A (415V,80kA)
Short-circuit coordination type 2, fusegG: 20A (690V,100kA), aM: 16A (690V, 100kA), BS88: 20A (415V, 80kA)
Aux. switch short-circuit protection, fusegG: 10 A (500 V, 1 kA)
3RT2015-1BE41 — Connection & Mounting
ParameterValue
Main circuit connectionscrew-type terminals
Aux. / control circuit connectionscrew-type terminals
Conductor cross-section, solid0.5 ... 4 mm²
Conductor cross-section, solid or stranded2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²), 2x 4 mm²
Conductor cross-section, finely stranded w/ ferrule2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Mounting methodscrew and snap-on mounting onto 35 mm DIN rail according to DIN EN 60715
Side-by-side mountingYes
3RT2015-1BE41 — Durability
ParameterValue
Durability (operating cycles, typ.)30 000 000
Durability with aux. switch block (cycles, typ.)10 000 000
3RT2015-1BE41 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C
Installation altitude, max.2 000 m
3RT2015-1BE41 — Mechanical
ParameterValue
Width45 mm
Height58 mm
Depth73 mm

Product details

It mounts on a 35 mm DIN rail per DIN EN 60715 via screw or snap-on fastening, and its compact footprint — 45 mm wide, 58 mm tall, 73 mm deep — fits tightly packed panels where every millimeter counts. The coil draws 10 A at 24 V rated value, with switching times of 7 to 13 ms DC and arcing time of 10 to 15 ms — fast enough for most motor and resistive load switching in control panels.

Wiring & Integration

Terminals accept solid or stranded wire: 0.5 to 4 mm² single, or 2x (0.5 to 1.5 mm²), 2x (0.75 to 2.5 mm²), or 2x 4 mm². The screw-type connection is field-proven for panel wiring — no special tooling needed.

Frequently asked questions

What is the closest functional second-source for 3RT2015-1BE41?

The 3RT2015-1BW42 is a peer with a different coil voltage; the 3RT2015-1AV01 and 3RT2015-1AV02 are also in the same S00 frame. Verify coil voltage and terminal type before substituting — the 1BE41 uses a 24 VDC coil and screw terminals.

Will 3RT2015-1BE41 drop into a panel specified for 3RT2015-1BW42?

Yes — both are size S00 with the same 45 x 58 x 73 mm footprint and DIN rail mounting. The difference is coil voltage: 1BE41 is 24 VDC, 1BW42 is a different coil. No rewiring of the main power path needed, but verify the coil supply.

What compliance documentation does Siemens provide for 3RT2015-1BE41?

Standard Siemens SIRIUS contactors carry CE, UL, CSA, and CCC certifications typically. Specific documents (RoHS, REACH, UL file) are available on request with an RFQ.

How do I get current pricing and availability for 3RT2015-1BE41?

Submit an RFQ through this listing. Pricing and lead time are confirmed at quote time based on current market sourcing — no automated stock figure is displayed.
