The 24 VDC coil with screw-type terminals is a straightforward fit for any standard 24 VDC control supply — no extra rectifier needed, just wire the coil and go. Size S00 means it occupies a 45 mm width on the DIN rail, with a depth of 73 mm and height of 58 mm — compact enough for tight enclosures, but leave the 10 mm clearance above and below for airflow and wiring access.
Rated for AC-3 duty at 750 operating cycles per hour — that's the standard motor-switching load (starting and running, no plugging). For AC-4 (inching, plugging, reversing under load) the rate drops to 250 cycles/h; the contactor's electrical life for main contacts is rated between 20,000 and 120,000 operations depending on the load. The mechanical life is a typical 30 million operations, so the moving parts outlast the contacts in most applications.
Screw-type terminals accept solid or stranded wire from 0.5 to 4 mm², or two conductors per terminal (e.g., 2x 0.75 to 2.5 mm²). Strip length and torque are standard for this class; no push-in or spring-cage here, so keep a screwdriver handy.
