Siemens 3RT2016-2JB41 — Contactors

Siemens 3RT2016-2JB41 SIRIUS coupling contactor, S00

MPN3RT2016-2JB41
Active

Siemens SIRIUS 3RT2016-2JB41 coupling contactor, size S00, 24 VDC coil, 10 A rated operating current at 24 V, spring-type terminals, 45 mm width, DIN-rail mount.

$23.66Ref. price · indicative, final on quote
Siemens 3RT2016-2JB41 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RT2016-2JB41 — Identification
ParameterValue
Contactor frame sizeS00
3RT2016-2JB41 — Ratings & Performance
ParameterValue
Rated operational current, AC-12, max.10 A
Rated operational current, AC-4 @ 400 V8.5 A
Rated value @ 400 V3 A
Rated value @ 500 V2 A
Rated value @ 690 V1 A
Rated value @ 230 V1 hp
Rated value @ 24 V10 A
Rated value @ 60 V2 A
Rated value @ 110 V1 A
Rated value @ 220 V0.3 A
3RT2016-2JB41 — Control & Coil
ParameterValue
Control supply voltage typeDC
3RT2016-2JB41 — Contacts & Poles
ParameterValue
Main poles3
Main NO contacts3
Auxiliary contact reliability1 faulty switching per 100 million (17 V, 1 mA)
3RT2016-2JB41 — Protection & Coordination
ParameterValue
Short-circuit coordination type 1, fusegG: 35A (690V,100kA), aM: 20A (690V,100kA), BS88: 35A (415V,80kA)
Short-circuit coordination type 2, fusegG: 20A (690V,100kA), aM: 16A (690V, 100kA), BS88: 20A (415V, 80kA)
Aux. switch short-circuit protection, fusegG: 10 A (500 V, 1 kA)
3RT2016-2JB41 — Connection & Mounting
ParameterValue
Main circuit connectionspring-loaded terminals
Aux. / control circuit connectionspring-loaded terminals
Conductor cross-section, solid0.5 ... 4 mm²
Conductor cross-section, solid or stranded2x (0,5 ... 4 mm²)
Conductor cross-section, finely stranded w/ ferrule2x (0.5 ... 2.5 mm²)
Mounting methodscrew and snap-on mounting onto 35 mm DIN rail according to DIN EN 60715
Side-by-side mountingYes
3RT2016-2JB41 — Durability
ParameterValue
Durability (operating cycles, typ.)30 000 000
3RT2016-2JB41 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C
Installation altitude, max.2 000 m
3RT2016-2JB41 — Mechanical
ParameterValue
Width45 mm
Height70 mm
Depth73 mm

Product details

Switching frequency and operating limits

The 3RT2016-2JB41: Maximum switching rates: 1,000 cycles/hour at AC-1, 750 cycles/hour at AC-2, AC-3, and AC-3e, and 250 cycles/hour at AC-4 — the AC-4 ceiling is the one that governs heavy inching or plugging duty. No built-in auxiliary switch — the contactor ships without auxiliary contacts; add a side-mount block if you need N/O or N/C feedback.

Current production — sourced to order

Lifecycle stage is current production — this is not a legacy or phase-out part. The SIRIUS S00 platform remains an active Siemens catalog line.

Frequently asked questions

What is the switching frequency at AC-3 duty?

Maximum 750 cycles per hour at AC-3 and AC-3e. At AC-4 (heavy inching/plugging) the maximum drops to 250 cycles per hour.

Does the 3RT2016-2JB41 include auxiliary contacts?

No, it ships without auxiliary contacts. The main contact configuration is 20-12 (2 N/O, 1 N/C) but no auxiliary switch block is fitted — order a side-mount auxiliary block separately if needed.

MPN
3RT2016-2JB41
