Siemens 3RT2017-1AP02 — Contactors

Siemens 3RT2017-1AP02 SIRIUS Power Contactor, Size S00, 24V

MPN3RT2017-1AP02
Active

Siemens SIRIUS power contactor, size S00, 3RT2017-1AP02, 24 V DC coil, screw terminals, 45 mm width, 73 mm depth.

$15.65Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RT2017-1AP02 — Identification
ParameterValue
Contactor frame sizeS00
3RT2017-1AP02 — Ratings & Performance
ParameterValue
Rated operational current, AC-12, max.10 A
Rated operational current, AC-4 @ 400 V8.5 A
Rated value @ 400 V3 A
Rated value @ 500 V2 A
Rated value @ 690 V1 A
Rated value @ 230 V2 hp
Rated value @ 24 V10 A
Rated value @ 60 V2 A
Rated value @ 110 V1 A
Rated value @ 220 V0.3 A
3RT2017-1AP02 — Control & Coil
ParameterValue
Control supply voltage typeAC
Rated value @ 50 Hz0.25
Rated value @ 50 Hz230 V
3RT2017-1AP02 — Contacts & Poles
ParameterValue
Main poles3
Main NO contacts3
Auxiliary contact reliability1 faulty switching per 100 million (17 V, 1 mA)
3RT2017-1AP02 — Protection & Coordination
ParameterValue
Short-circuit coordination type 1, fusegG: 50A (690V,100kA), aM: 20A (690V,100kA), BS88: 35A (415V,80kA)
Short-circuit coordination type 2, fusegG: 20A (690V,100kA), aM: 16A (690V, 100kA), BS88: 20A (415V, 80kA)
Aux. switch short-circuit protection, fusegG: 10 A (500 V, 1 kA)
3RT2017-1AP02 — Connection & Mounting
ParameterValue
Main circuit connectionscrew-type terminals
Aux. / control circuit connectionscrew-type terminals
Conductor cross-section, solid0.5 ... 4 mm²
Conductor cross-section, solid or stranded2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²), 2x 4 mm²
Conductor cross-section, finely stranded w/ ferrule2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Mounting methodscrew and snap-on mounting onto 35 mm DIN rail according to DIN EN 60715
Side-by-side mountingYes
3RT2017-1AP02 — Durability
ParameterValue
Durability (operating cycles, typ.)30 000 000
Durability with aux. switch block (cycles, typ.)10 000 000
3RT2017-1AP02 — Environmental
ParameterValue
Operating temperature range-25 ... +60 °C
Storage temperature range-55 ... +80 °C
Installation altitude, max.2 000 m
3RT2017-1AP02 — Mechanical
ParameterValue
Width45 mm
Height58 mm
Depth73 mm
3RT2017-1AP02 — Specifications
ParameterValue
At AC4 ... 15 ms

Product details

It is a current-production part. Rated for a 24 V DC coil, it pulls in at 10 A at 24 V rated value, and carries a solid switching frequency of 1 000 cycles per hour in AC-1 duty (resistive loads) and 750 cycles per hour in AC-3 (motor starting). That means it'll handle a conveyor start-stop cycle every 4.8 seconds in motor duty without overheating.

Mounting and wiring — what fits

At 45 mm wide and 73 mm deep, it's a compact footprint — you can pack several side-by-side with 6 mm spacing between units. You can double up two conductors per clamp — 2x (0.5...1.5 mm²), 2x (0.75...2.5 mm²), or 2x 4 mm². Strip length is straightforward, no special ferrule needed for solid wire.

Environment and auxiliaries

That's a lot of starts before the springs wear out.

Frequently asked questions

What is 3RT2017-1AP02's depth?

The depth is 73 mm.

What wire sizes does the 3RT2017-1AP02 accept?

Solid or stranded wire from 0.5 to 4 mm², with double-conductor capability up to 2x 4 mm².
