Spring-type terminals on the magnet coil accept solid or stranded wire from 0.5 to 4 mm² (2× 0.5–4 mm² per clamp). Strip and push — no screw torque to verify, which speeds wiring on repetitive builds.
Switching Performance & Thermal Limits
Rated for up to 1 000 switching cycles per hour in AC-1 resistive duty, 750/h in AC-3 motor switching, and 250/h in AC-4 (inching/plugging).
Integral auxiliary switch rated at 10 A at 24 V, 2 A at 48/60 V, 1 A at 110 V, 0.9 A at 125 V, 0.3 A at 220 V, and 0.2 A at 440 V. These are the continuous thermal current limits through the aux contacts — match your control voltage to the column.
