It snaps onto a 35 mm DIN rail per DIN EN 60715 and accepts screw-type terminations on both coil and main contacts, with a solid or stranded wire range of 0.5 to 4 mm². The 24 VDC coil draws 0.24 A holding power at both 50 and 60 Hz, and the contactor carries a 10 A rated current at 24 V and a 2 hp rating at 230 V.
The AC-3 switching frequency of 750 operations per hour tells you this contactor is rated for frequent motor starting — typical for conveyor or pump duty cycles. The auxiliary switch (built-in) lets you wire a feedback signal to the PLC without adding a separate block.
Mounting and clearance — panel integration
For a panel builder, the 73 mm depth means it fits standard 200 mm deep enclosures without crowding the door-mounted devices.
