Siemens 3RT2326-1AF00 — Contactors

Siemens 3RT2326-1AF00 SIRIUS Contactor, Size S0, 97 mm Depth

MPN3RT2326-1AF00

Active

Siemens SIRIUS 3RT2326-1AF00 contactor, size S0, screw and snap-on DIN rail mounting, 97 mm depth, 60 mm width, 85 mm height, auxiliary contacts rated 10 A at 24 V AC and 230 V AC.

Request quote

Siemens 3RT2326-1AF00 datasheet (PDF)

StockContact for availability

Lead timeIn Stock wk

MOQ1 pcs

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

How we verify every order →

Specifications

Identification

3RT2326-1AF00 — Identification
Parameter	Value
Contactor frame size	S0

Ratings & Performance

3RT2326-1AF00 — Ratings & Performance
Parameter	Value
Rated operational current, AC-12, max.	10 A
Rated operational current, AC-4 @ 400 V	7.5 kW
Rated value @ 400 V	3 A
Rated value @ 500 V	2 A
Rated value @ 690 V	1 A
Rated value @ 230 V	10 A
Rated value @ 24 V	10 A
Rated value @ 60 V	6 A
Rated value @ 110 V	1 A
Rated value @ 220 V	0.3 A

Control & Coil

3RT2326-1AF00 — Control & Coil
Parameter	Value
Control supply voltage type	AC
Rated value @ 50 Hz	0.25
Rated value @ 50 Hz	110 V

Contacts & Poles

3RT2326-1AF00 — Contacts & Poles
Parameter	Value
Main poles	4
Main NO contacts	4
Auxiliary contact reliability	1 faulty switching per 100 million (17 V, 1 mA)

Protection & Coordination

3RT2326-1AF00 — Protection & Coordination
Parameter	Value
Short-circuit coordination type 1, fuse	gG: 63 A (690 V, 100 kA)
Short-circuit coordination type 2, fuse	gG: 20 A (690 V, 100 kA)
Aux. switch short-circuit protection, fuse	gG: 10 A (690 V, 1 kA)

Connection & Mounting

3RT2326-1AF00 — Connection & Mounting
Parameter	Value
Main circuit connection	screw-type terminals
Aux. / control circuit connection	screw-type terminals
Conductor cross-section, solid	2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Conductor cross-section, solid or stranded	2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Conductor cross-section, finely stranded w/ ferrule	2x (0.5 ... 1.5 mm²), 2x (0.75 ... 2.5 mm²)
Mounting method	screw and snap-on mounting onto 35 mm DIN rail according to DIN EN 60715
Side-by-side mounting	Yes

Durability

3RT2326-1AF00 — Durability
Parameter	Value
Durability (operating cycles, typ.)	10 000 000
Durability with aux. switch block (cycles, typ.)	10 000 000

Environmental

3RT2326-1AF00 — Environmental
Parameter	Value
Operating temperature range	-25 ... +60 °C
Storage temperature range	-55 ... +80 °C
Installation altitude, max.	2 000 m

Mechanical

3RT2326-1AF00 — Mechanical
Parameter	Value
Width	60 mm
Height	85 mm
Depth	97 mm

Specifications

3RT2326-1AF00 — Specifications
Parameter	Value
At AC	4 ... 16 ms

Product details

Auxiliary contact ratings — signal switching limits

The 3RT2326-1AF00: The auxiliary switch is rated 10 A at both 24 V AC and 230 V AC — this covers most PLC input and relay coil switching in a 24 VDC or 230 VAC control circuit without derating at those common voltages.
