Rated for 690 V, the relay handles line voltages up to that level. The auxiliary contact block is integrated and rated for switching: 2 A at 24 V, 3 A at 120 V, 2 A at 230 V, 1 A at 400 V, and 0.75 A at 690 V — these are the contact ratings for the trip-indication and alarm circuits, not the main power path. The relay carries a note: "for message 'Tripped'" — this is the auxiliary contact that changes state when the overload trips, providing a signal back to a PLC or indicator lamp.
Mounts directly onto a contactor (contactor mounting) in any position. Dimensions: 45 mm wide, 76 mm high, 70 mm deep — fits standard S00 contactor footprints. Main circuit terminals are screw-type, accepting 2×(0.5…1.5 mm²) or 2×(0.75…2.5 mm²) solid or stranded wire. The screwdriver shaft should be 5…6 mm diameter with a Pozidriv PZ 2 tip. Temperature compensation is active from -40 to +60 °C, keeping the trip curve accurate across that ambient range.
Substance compliance: the relay meets the substance prohibitance date of 10/01/2009, indicating RoHS compliance for materials restricted as of that date.
