Siemens 3RV1918-5A — Motor Protection Circuit Breakers (MPCB)

Siemens 3RV1918-5A SIRIUS Auxiliary Switch, 10A Max, Solder

MPN3RV1918-5A

Siemens SIRIUS auxiliary switch, Size S00, 1 NO + 1 NC, solder pin connectors, max 10A.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

3RV1918-5A — Identification
ParameterValue
SeriesSIRIUS
Frame sizeS00
3RV1918-5A — Environmental
ParameterValue
Operating temperature-20 ... +60°C
Storage temperature-50 ... +80°C
3RV1918-5A — Other specifications
ParameterValue
At 24 V2A
At 110 V0.5A
At 220 V0.25A
At 230 V4A
At 400 V3A
At 690 V10A
At AC-15 at 690 v rated value1A
Type of electrical connection for auxiliary and control circuitsolder pin connectors
Number of CO contacts of auxiliary contacts instantaneous contact0
Number of NC contacts for auxiliary contacts instantaneous contact1
Number of NO contacts for auxiliary contacts instantaneous contact1

Product details

It provides one normally-open and one normally-closed instantaneous contact, terminated via solder pin connectors — a fixed connection method that means you're wiring it directly into the PCB or terminal block, not clipping into a spring-cage or screw terminal.

The maximum switching capability is 10 A, but that's only at 690 V AC-15 (solenoid/contactor coil duty). At the more common 24 V DC control voltage it's rated 2 A; at 110 V AC it drops to 0.5 A, and at 230 V AC it handles 4 A. The 690 V / 10 A rating is for the highest-voltage industrial control circuits — most panels run 400 V or less, so the practical limit is the lower current at your line voltage.

Panel Integration — Solder Pin Fit

This block snaps onto the front of a Size S00 Siemens circuit breaker. The solder pin connection means it is intended for a fixed wiring harness or PCB — not for field rewiring. Verify the pin spacing matches your terminal layout before adding to the BOM; the pins are not adjustable.

Frequently asked questions

Does 3RV1918-5A have solder pin or screw terminals?

It uses solder pin connectors for both auxiliary and control circuits — a fixed connection method, not screw or spring-cage terminals.
