Rated breaking capacity reaches 100 kA at 240 V, 400 V, and 500 V, and 10 kA at 690 V. Ground fault detection is not included — that would require a separate module or a different family variant.
Any mounting position is allowed, so panel layout is flexible. Main circuit terminals accept solid or stranded conductors: 2x (0.75 to 2.5 mm²) or 2x 4 mm². Screw terminals (M3) are standard, so no special tooling is needed for termination. Clearance distances: 50 mm upwards and downwards, 30 mm to the side, 0 mm forwards and backwards. That 0 mm backwards means it can sit flush against the back panel or another device — useful in tight enclosures.
