Rated for 100 kA breaking capacity at 240 V, 30 kA at 400 V, 5 kA at 500 V, and 2 kA at 690 V, it handles high prospective fault currents on industrial 480 V panels without needing an upstream current-limiting fuse for most installations.
Depth is 97 mm, which matches the contactor depth in the same frame class; no extra gland-plate projection.
Motor ratings and coordination
Rated for motor loads: 2 hp at 230 V, 5 hp at 220/230 V, 10 hp at 460/480 V. The AC-3e switching capacity is 15 operations per hour maximum — fine for a pump or fan cycling a few times an hour, not for a jogging or reversing application. Screw terminals accept 2x 0.75–2.5 mm² or 2x 4 mm² solid/stranded. No ground-fault or phase-failure detection built in; that's handled by the upstream motor protection relay or the contactor's electronic overload.
