32 A at 40°C — the rating that governs motor starting
The 3RW3027-1BB14: That figure is the continuous motor full-load current it can start and run through the integrated bypass once the motor reaches speed.
S0 frame, 45 mm — panel fit constraints
The S0 frame size measures 45 mm wide by 125 mm high by 150 mm deep. That 45 mm width is the standard S0 DIN-rail slot — it snaps onto the rail and can also be screw-mounted. Clearance: 60 mm above and 40 mm below for ventilation; 15 mm at the sides.
Integrated bypass and control supply flexibility
The built-in bypass contactor shorts the thyristors after start, dropping the heat dissipation to near zero during run — a meaningful advantage in a sealed panel. Control supply accepts 110-230 V DC, wide enough to work across common DC bus voltages without a separate power supply. No external reset and no motor overload protection integrated — plan for a separate overload relay upstream.
