Siemens 3SE2200-1G
MPN3SE2200-1G
POSITION SWITCH IN MOLDED PLASTIC ENCLOSURE 30MM, SNAP-ACTION CONTACTS 1NO+1NC, SWIVEL LEVER 1XM20X1.5 W. PLASTIC ROLLER 13MM
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
Identification
| Parameter | Value |
|---|---|
| Product designation | position switch |
Switching & Safety
| Parameter | Value |
|---|---|
| Auxiliary NO contacts | 1 |
| Auxiliary NC contacts | 1 |
| Circuit principle | snap-action contacts |
| Switching function design | positive opening |
| Active principle | mechanical |
| Safety-related switching contacts | 1 |
| Suitable as safety switch | Yes |
| Switching contact design | mechanical |
| Safety-related interface connector | without |
Mechanical
| Parameter | Value |
|---|---|
| Actuating element design | twist lever |
| Standard-compliant actuator head | EN 50047, design A |
| Enclosure material | glass fiber reinforced thermoplast |
| Fastening method | screw fixing |
| Length | 103.5 mm |
| Width | 31 mm |
| Enclosure coating | Other types |
| Housing design standard | design complying with EN 50047 |
Environmental
| Parameter | Value |
|---|---|
| IP protection rating | IP67 |
| Operating temperature range | -30 ... +85 °C |
Wiring
| Parameter | Value |
|---|---|
| Electrical connection type | screw-type terminals |
| Interface connector design | without |
MPN
3SE2200-1G
