Breaking capacity is 330 kA at 240 V AC, dropping to 242 kA at 415 V and 440 V, 187 kA at 500 V, and 9 kA at 690 V.
The continuous current rating is temperature-dependent: 630 A at 40 °C, 612 A at 45 °C, 593 A at 50 °C, 575 A at 55 °C, 557 A at 60 °C, 538 A at 65 °C, and 520 A at 70 °C. For a panel with internal ambient above 40 °C, the designer must apply the appropriate derating factor from this table rather than relying on the 40 °C nameplate. Dimensions are 248 mm height, 138 mm width, 110 mm depth. Maximum power loss is 162 W at rated load. This figure drives the ventilation requirement inside the enclosure — a sealed box with no airflow will need a thermal calculation to stay below the 70 °C operating maximum.
