The Siemens 3VA4180-4ED34-0AA0 is a SENTRON 3-pole molded-case circuit breaker (MCCB) rated 80 A at 40 °C ambient, with a TM210 thermal-magnetic release that provides fixed overload and short-circuit protection — no adjustable I²t curve, so it's a straight swap-in for a panel design that already calls for that trip characteristic. Breaking capacity hits 65 kA at 240 VAC and 25 kA at 480 VAC, which covers most North American 480Y/277 V distribution panels and industrial motor control centers where the available fault current is known to be under that threshold. Rated operating voltage goes to 690 VAC.
The 80 A rating holds at 40 °C; above that, the continuous current derates in 1–2 A steps per 5 °C rise, down to 70 A at 70 °C. Maximum power dissipation is 16.5 W, which is modest for an 80 A frame.
Footprint is 76.2 mm wide, 129.4 mm tall, 75.1 mm deep — a standard 3-pole MCCB form factor that drops into most SENTRON or third-party distribution blocks without panel rework. If your BOM calls for shunt trip or remote signaling, you need a different variant in the 3VA family.
UL file SEAB covers the UL 489 listing for North American installations. RoHS and REACH compliance documentation is available from Siemens for this order code.
