What it is and what the ratings mean
The Siemens 4EU4321-5DA00-0A is a three-phase commutating choke (line reactor) for converter applications — the component that sits between the drive's input rectifier and the DC link to limit current rise rates and reduce harmonic distortion. Its rated current of 639 A (maximum continuous 710 A) at 750 V AC, 50 Hz, tells you the thermal capacity for a continuous-duty converter line-up; the 888 A peak current figure governs short-duration overloads the choke must survive without saturating. The 0.06 mH inductance and 4 % relative inductive voltage drop at rated current define the impedance the choke presents to the switching edges — that 4 % figure is the voltage drop across the choke at full load, a standard design point for commutating chokes in this power class.
Where it fits and how it's built
This is a panel-mount component, not a DIN-rail device — the 0.46 m width, 0.435 m height, and 0.265 m depth mean it needs dedicated floor or shelf space inside the enclosure, with clearance for airflow around the IP00 (open-frame) construction. The flat-type terminals on the main current circuit accept busbar or large cable lugs; no screw-clamp or spring-cage termination here. Thermal class H (180 °C insulation system) per IEC 60085 means the winding insulation can sustain the 472 W coil loss plus 321 W iron-core loss at the 40 °C ambient rating without exceeding its temperature limit. The open-frame design (IP00) assumes installation inside a clean, dry cabinet — not for washdown or outdoor exposure.
