Siemens SENTRON 5SJ4 series, miniature circuit breaker 5SJ4113-6HG40, 1-pole, B-characteristic, 13 A rated at 30/40 °C, IP20, DIN rail mount.
| Parameter | Value |
|---|---|
| Product designation | Miniature circuit breakers |
| Brand name | SENTRON |
| Number of poles | 1 |
| Pole design | 1P |
| Application suitability | Mechanical engineering / industry |
| Parameter | Value |
|---|---|
| Tripping characteristic class | B |
| Overvoltage category | 3 |
| Parameter | Value |
|---|---|
| Mounting position | any |
| Fastening method | on standard mounting rail |
| Combined terminal, top | Yes |
| Combined terminal, bottom | Yes |
| Width | 18 mm |
| Height | 90 mm |
| Depth | 70 mm |
| Installation depth | 70 mm |
| Modular width units | 1 |
| Torque, min. | -40 °C |
| Torque, max. | 75 °C |
| Sealable | Yes |
| Parameter | Value |
|---|---|
| IP protection class | IP20, with connected conductors, IP 40 in the handle range |
| Pollution degree | 3 |
| Halogen-free | Yes |
| Silicone-free | Yes |
The 13 A rating holds at both 30 °C and 40 °C ambient; above that it derates predictably down to 11.4 A at 60 °C. The IP20 body (IP40 in the handle area) is fine for enclosed panels; keep the front sealed if washdown is nearby.
Sealable, halogen-free, silicon-free construction — relevant for food processing or clean-room panels where outgassing or tamper-proofing is specified.
Depth is 70 mm, width 18 mm (one modular unit), height 90 mm. It mounts on a standard DIN rail.
The part is halogen-free and silicon-free. It carries an IP20/IP40 protection rating and is designed for overvoltage category III, pollution degree 3. Specific RoHS/REACH/UL declarations should be requested per your compliance audit.
