Siemens 5SJ4145-6HG40 — 1-Pole MCB (DIN Rail)

Siemens SENTRON 5SJ4145-6HG40 MCB, 1-Pole, 45 A, B Curve

MPN5SJ4145-6HG40
Active

Siemens SENTRON 5SJ4 series, miniature circuit breaker 5SJ4145-6HG40, 1-pole, 45 A rated, B tripping characteristic, 10 kA breaking capacity, 1 MW.

$81.23Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5SJ4145-6HG40 — Identification
ParameterValue
Product designationMiniature circuit breakers
Brand nameSENTRON
Number of poles1
Application suitabilityMechanical engineering / industry
5SJ4145-6HG40 — Electrical & Protection
ParameterValue
Tripping characteristic classB
Rated value (EN 60898)10 kA
Overvoltage category3
5SJ4145-6HG40 — Mounting & Connection
ParameterValue
Mounting positionany
Fastening methodon standard mounting rail
Combined terminal, topYes
Combined terminal, bottomYes
Width18 mm
Height90 mm
Depth70 mm
Installation depth70 mm
Modular width units1
Torque, min.-40 °C
Torque, max.75 °C
SealableYes
5SJ4145-6HG40 — Environmental
ParameterValue
IP protection classIP20, with connected conductors, IP 40 in the handle range
Pollution degree3
Halogen-freeYes
Silicone-freeYes

Product details

At 45 °C it derates to 43.7 A, at 50 °C to 42.8 A, at 55 °C to 41.7 A, and at 60 °C to 41 A. That thermal curve is what you check when the breaker sits next to heat-producing loads or in a sealed enclosure.

Deployment context and approvals

IP20 with connected conductors, IP40 in the handle range — fine for enclosed panel mounting, not for washdown zones. Vibration resistance rated at 50 m/s² from 25 to 150 Hz and 60 m/s² at 35 Hz (4 s), so it holds up on machine-mounted sub-panels near rotating equipment. Suitability noted for mechanical engineering and industry. Halogen-free and silicon-free construction, sealable for tamper-evident applications. The product designation follows IEC 81346-2 and DIN EN 61346-2 function code F (protective device).

Frequently asked questions

What are the key ratings for this MCB?

1-pole, 45 A rated current, B tripping characteristic, 10 kA breaking capacity per EN 60898, 60 V DC maximum. Occupies 1 modular width (18 mm) on DIN rail.

What compliance documentation is available?

The part carries EN 60898 rating for breaking capacity. It is halogen-free and silicon-free. The design follows IEC 81346-2 and DIN EN 61346-2 function code F.
