Siemens 5SJ4145-7HG40 — 1-Pole MCB (DIN Rail)

Siemens 5SJ4145-7HG40 SENTRON MCB, 1P C 45A

MPN5SJ4145-7HG40
Active

Siemens SENTRON 5SJ4 series, miniature circuit breaker 5SJ4145-7HG40, 1-pole, C-curve, 45 A at AC, 70 mm depth, 18 mm width, current production.

$41.91Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5SJ4145-7HG40 — Identification
ParameterValue
Product designationMiniature circuit breakers
Brand nameSENTRON
Number of poles1
Application suitabilityMechanical engineering / industry
5SJ4145-7HG40 — Electrical & Protection
ParameterValue
Tripping characteristic classC
Rated value (EN 60898)10 kA
Overvoltage category3
5SJ4145-7HG40 — Mounting & Connection
ParameterValue
Mounting positionany
Fastening methodon standard mounting rail
Combined terminal, topYes
Combined terminal, bottomYes
Width18 mm
Height90 mm
Depth70 mm
Installation depth70 mm
Modular width units1
Torque, min.-40 °C
Torque, max.75 °C
SealableYes
5SJ4145-7HG40 — Environmental
ParameterValue
IP protection classIP20, with connected conductors, IP 40 in the handle range
Pollution degree3
Halogen-freeYes
Silicone-freeYes

Product details

The Siemens 5SJ4145-7HG40 is a SENTRON miniature circuit breaker (MCB), 1-pole, C-curve, rated 45 A at AC (also 45 A at 40 °C ambient). It is the standard panel-protection building block for branch circuits in industrial control cabinets — mechanical engineering and industry applications per the listing.

Rated 45 A at 30 °C and 40 °C, derated to 43.7 A at 45 °C, 42.8 A at 50 °C, 41.7 A at 55 °C, and 41 A at 60 °C. Maximum DC voltage is 60 V, so it's fine for 48 VDC control circuits but not for a 125 VDC battery bank. Overvoltage category 3 and pollution degree 3 mean it's rated for the fixed-installation environment inside an industrial enclosure.

Width is 18 mm (one modular unit), depth 70 mm, height 90 mm. Terminals are combined (top and bottom) — not tunnel type — so you land a ring or fork lug. Terminal tightening torque is 3.5 Nm for copper conductors rated 60/75 °C. Sealable, halogen-free, silicon-free. IP20 with connected conductors, IP40 in the handle area.

Frequently asked questions

What are the key ratings of the 5SJ4145-7HG40?

1-pole, C-curve, rated 45 A at AC (45 A at 40 °C), max DC 60 V, width 18 mm, depth 70 mm, operating temperature -40 to 75 °C.
