Siemens 5SJ4260-8HG41 — 2-Pole MCB (DIN Rail)

Siemens 5SJ4260-8HG41 SENTRON MCB, 2-Pole, D-Curve, 60A

MPN5SJ4260-8HG41

Active

Siemens SENTRON 5SJ4260-8HG41, 2-pole miniature circuit breaker, D-curve, 60 A AC, 36 mm wide, 70 mm depth, IP20/IP40.

$552.12Ref. price · indicative, final on quote

Add to RFQ

Siemens 5SJ4260-8HG41 datasheet (PDF)

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5SJ4260-8HG41 — Identification
Parameter	Value
Product designation	Miniature circuit breakers
Brand name	SENTRON
Application environment	Mechanical engineering / industry

5SJ4260-8HG41 — Electrical
Parameter	Value
Number of poles	2

5SJ4260-8HG41 — Protection
Parameter	Value
Tripping characteristic class	D
Overvoltage category	3

5SJ4260-8HG41 — Mechanical
Parameter	Value
Modular width units	2
Width	36 mm
Height	110 mm
Depth	70 mm
Installation depth	70 mm
Mounting position	any
Min.	-40 °C
Max.	75 °C
Protection degree (IP)	IP20, with connected conductors, IP 40 in the handle range

5SJ4260-8HG41 — Environmental
Parameter	Value
Pollution degree	3

Product details

2-pole D-curve MCB for branch-circuit protection

The DC rating is 60 V maximum, making this breaker suitable for DC control circuits and small battery banks within that voltage limit.

Terminal tightening torque is specified at 3.5 Nm for copper conductors at 60/75°C. Protection rating: IP20 with conductors connected, IP40 at the handle area. Sealable cover is provided for tamper‑proof installation.

Rated for ambient temperature from -40°C to 75°C, with vibration resistance up to 50 m/s² (25–150 Hz) and 60 m/s² at 35 Hz. Suitable for mechanical engineering and industrial environments.
