Siemens 5SU1354-7KK08 — Residual Current Breakers (RCCB/RCBO)

SENTRON 5SU1354-7KK08 RCBO, 2-pole, 8 A, C-curve, 10 kA

MPN5SU1354-7KK08
Active

SENTRON 5SU1354-7KK08 RCBO, 2-pole, 8 A, C-curve, 10 kA (EN 60898), 20 kA (IEC 60947-2), Type A RCD, 2 MW, halogen-free.

$108.00 – $149.58Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

5SU1354-7KK08 — Electrical Ratings
ParameterValue
Number of poles2
Overvoltage categoryIII
5SU1354-7KK08 — Identification
ParameterValue
Product designationRCBO
Product design / constructionInstantaneous
5SU1354-7KK08 — Mechanical
ParameterValue
Mounting positionany
Width in modular units2
Maximum75 °C
Minimum-40 °C
Width36 mm
Height90 mm
Depth77 mm
Installation depth70 mm
5SU1354-7KK08 — Environmental
ParameterValue
IP degree of protectionIP20, if the distribution board is installed, with connected conductors
5SU1354-7KK08 — Electrical
ParameterValue
Tripping Characteristic ClassC

Product details

It combines overcurrent protection and Type A residual current detection in a single 2-module-width (36 mm) package — a space-saving fit for DIN-rail distribution boards where separate MCB+RCCD won't fit.

Derating and mounting

The 8 A rating holds at 30 °C; at 40 °C it derates to 7.52 A, and at 50 °C to 6.96 A. At 70 °C the continuous rating drops to 5.84 A. The IP20 rating applies only when the distribution board is installed with conductors connected — bare terminals are not finger-safe outside the enclosure.

Halogen-free and silicon-free construction meets clean-material requirements for sensitive environments like data centers or medical facilities.

Frequently asked questions

What is the closest functional second-source to 5SU1354-7KK08?

The 5SL4363-7 is a 2-pole RCBO from the same SENTRON family with similar ratings, but it uses a different residual current characteristic (Type AC vs Type A). Verify the fault type your circuit requires before substituting.

What are the key dimensions of 5SU1354-7KK08?

Width 36 mm (2 modular units), height 90 mm, depth 77 mm. Installation depth is 70 mm.

Will 5SU1354-7KK08 drop into a panel specified around 5SL4363-7 without rewiring?

The 5SU1354-7KK08 and 5SL4363-7 share the same 2-module-width footprint and DIN-rail mounting, so mechanical fit is the same. However, the 5SU1354-7KK08 is Type A residual current, while the 5SL4363-7 is Type AC — the wiring is identical, but the protection characteristic differs. No rewiring needed, but verify the RCD type matches your load.

What compliance documentation does Siemens provide for 5SU1354-7KK08?

The part is designed to EN 60898 and IEC 60947-2, and carries a CE mark for the European market. It is halogen-free and silicon-free. Specific declarations (RoHS, REACH) are available from Siemens on request.
