Siemens 5SU1356-1DA06 — Residual Current Breakers (RCCB/RCBO)

Siemens 5SU1356-1DA06 FI/LS Protector, 6A C, 30mA, 6kA

MPN5SU1356-1DA06

Siemens 5SU1356-1DA06 FI/LS protector, Type AC (WS), 30mA, 6kA, 1+N-pole, C-curve 6A, pig-tail, D=70mm.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Product details

The Siemens 5SU1356-1DA06 is a combined residual-current and miniature circuit breaker (RCBO) — an FI/LS protector — in a 1+N-pole format. The pig-tail neutral connection is a factory-fitted flexible lead, not a busbar stab — factor that into your panel wiring plan.

The 70 mm depth (D=70MM) is the dimension from the DIN-rail mounting surface to the front of the device — standard for Siemens 5SU series RCBOs. The 1+N-pole width occupies a single modular unit (roughly 18 mm per pole, but confirm the exact width from the product drawing for your busbar layout). The pig-tail neutral exits the bottom; plan your neutral busbar routing accordingly to keep the bend radius within the enclosure's wiring space.

Frequently asked questions

What is the breaking capacity and sensitivity of 5SU1356-1DA06?

It has a 6 kA breaking capacity and a 30 mA residual-current sensitivity (Type AC for sinusoidal faults), with a C-curve 6 A overcurrent characteristic.

Where can I buy 5SU1356-1DA06?

Sourced and quoted to order against an RFQ through independent distribution; availability and current pricing are confirmed at quote time.
