Siemens SENTRON RCBO, 1P+N, 6 A at 30 °C, C-trip characteristic, 6 kA / 25 kA dual breaking capacity, 2 MW, depth 77 mm.
| Parameter | Value |
|---|---|
| Number of poles | 2 |
| Overvoltage category | III |
| Parameter | Value |
|---|---|
| Product designation | RCBO |
| Product design / construction | Instantaneous |
| Parameter | Value |
|---|---|
| Mounting position | any |
| Width in modular units | 2 |
| Maximum | 75 °C |
| Minimum | -40 °C |
| Width | 36 mm |
| Height | 90 mm |
| Depth | 77 mm |
| Installation depth | 70 mm |
| Parameter | Value |
|---|---|
| IP degree of protection | IP20, if the distribution board is installed, with connected conductors |
| Parameter | Value |
|---|---|
| Tripping Characteristic Class | C |
The 5SU1356-7KK06: Mounting position is unrestricted – any orientation – and the supply can enter from top or bottom. The 36 mm width (2 modular units) fits standard DIN-rail enclosures, and the depth of 77 mm (70 mm inside the board) leaves clearance for wiring troughs. Overvoltage category III and pollution degree 2 suit it for fixed installation downstream of the main distribution board. The IP20 rating applies once the board is closed and cables are installed.
Width is 36 mm (2 modular units), depth 77 mm (70 mm installation depth), height 90 mm.
