Siemens 5SY4108-7
MPN5SY4108-7
Active
Miniature circuit breaker 230/400 V 10kA, 1-pole, C, 8A, D=70 mm
$10.67Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jun 2026
Specifications
| Parameter | Value |
|---|---|
| Product designation | Miniature circuit breaker |
| Brand name | SENTRON |
| Number of poles | 1 |
| Pole design | 1P |
| Application suitability | Mechanical engineering / industry |
| Parameter | Value |
|---|---|
| Tripping characteristic class | C |
| Energy limitation class | 3 |
| Overvoltage category | III |
| Parameter | Value |
|---|---|
| Mounting position | any |
| Fastening method | Quick assembly system |
| Combined terminal, top | Yes |
| Combined terminal, bottom | Yes |
| Width | 18 mm |
| Height | 90 mm |
| Depth | 76 mm |
| Installation depth | 70 mm |
| Modular width units | 1 |
| Torque, min. | -40 °C |
| Torque, max. | 75 °C |
| Sealable | Yes |
| Parameter | Value |
|---|---|
| IP protection class | IP20, with connected conductors |
| Pollution degree | 3 |
| Halogen-free | Yes |
| Silicone-free | Yes |
MPN
5SY4108-7
