Siemens 5SY6250-8 — 2-Pole MCB (DIN Rail)

Siemens 5SY6250-8 SENTRON MCB, 2P D 50 A, 6/10 kA

MPN5SY6250-8

Siemens SENTRON 5SY6 series, miniature circuit breaker, 2-pole, D-curve, 50 A, 400 V AC, 6 kA (EN 60898) / 10 kA (IEC 60947-2), 2 MW, IP20.

$299.76Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

5SY6250-8 — Identification
ParameterValue
Product designationMiniature circuit breaker
Brand nameSENTRON
Application environmentMechanical engineering / industry
5SY6250-8 — Electrical
ParameterValue
Number of poles2
5SY6250-8 — Protection
ParameterValue
Tripping characteristic classD
Overvoltage categoryIII
5SY6250-8 — Mechanical
ParameterValue
Width36 mm
Height90 mm
Depth76 mm
Installation depth70 mm
Mounting positionany
Min.-40 °C
Max.75 °C
Protection degree (IP)IP20, with connected conductors

Product details

The Siemens 5SY6250-8 is a 2-pole SENTRON miniature circuit breaker rated 50 A at 400 V AC, with a D tripping characteristic. The 6 kA breaking capacity per EN 60898 covers standard domestic/commercial fault levels; the 10 kA per IEC 60947-2 covers industrial panels where higher prospective fault current is expected. It also carries a 5 kA rating per UL 1077 and CSA C22.2 No. 235, so it's accepted in North American control-panel applications.

Mounting position is any, so vertical or horizontal busbar feeds work. Depth is 76 mm, installation depth 70 mm; that's standard for the SENTRON 5SY6 family, so it fits existing panel layouts without re-spacing.

Frequently asked questions

How do I get current pricing and availability for 5SY6250-8?

Submit an RFQ through this listing. The part is sourced to order via independent distribution; a confirmed price and lead time are provided at quote time.

Will 5SY6250-8 drop into a panel specified around 5SY6613-8 without rewiring?

Both are 2-pole SENTRON 5SY6 MCBs with the same 36 mm width and 76 mm depth, so the mechanical fit is identical. The difference is the rating: 5SY6250-8 is a 50 A D-curve; 5SY6613-8 is a 13 A B-curve. If the panel was designed for a 13 A B-curve, dropping in a 50 A D-curve changes the protection — verify the load and cable sizing first.

What compliance documentation does Siemens provide for 5SY6250-8?

The SENTRON 5SY6 series carries RoHS, REACH, and UL/IEC declarations. The part is rated per EN 60898 (6 kA), IEC 60947-2 (10 kA), and UL 1077 / CSA C22.2 No. 235 (5 kA).
