Siemens 5SY6503-7 — 1-Pole MCB (DIN Rail)

Siemens SENTRON 5SY6503-7 MCB, C-curve 2-pole 1P+N, 6/30 kA

MPN5SY6503-7
Active

Siemens SENTRON 5SY6503-7, miniature circuit breaker, C-curve, 2-pole 1P+N, 6 kA (EN 60898) / 30 kA (IEC 60947-2), 230 V AC, 60 V DC.

$13.97Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

5SY6503-7 — Identification
ParameterValue
Product designationMiniature circuit breaker
Brand nameSENTRON
Number of poles2
Pole design1P+N
Application suitabilityMechanical engineering / industry
5SY6503-7 — Electrical & Protection
ParameterValue
Tripping characteristic classC
Energy limitation class3
Overvoltage categoryIII
5SY6503-7 — Mounting & Connection
ParameterValue
Mounting positionany
Fastening methodQuick assembly system
Combined terminal, topYes
Combined terminal, bottomYes
Width36 mm
Height90 mm
Depth76 mm
Installation depth70 mm
Modular width units2
Torque, min.-40 °C
Torque, max.75 °C
SealableYes
5SY6503-7 — Environmental
ParameterValue
IP protection classIP20, with connected conductors
Pollution degree3
Halogen-freeYes
Silicone-freeYes

Product details

That switched neutral makes it a fit for single-phase final subcircuits where isolating the neutral on fault is required, common in European panel builds.

Mounting position is unrestricted — vertical, horizontal, or inverted — which simplifies layout in a crowded panel. Depth behind the panel is 70 mm installation depth; overall depth is 76 mm, so gland-plate clearance is straightforward. IP20 with connected conductors — standard for inside-enclosure use.

Ambient temperature range is -40 °C to 75 °C, with humidity derating above 55 °C: 95% RH up to 55 °C, 55% RH at 70 °C, 35% RH at 75 °C. Lifecycle status is current production. Compliance documentation covers IEC/EN 60898-1, IEC/EN 60947-2, and UL 1077. The UL 1077 rating is 5 kA at 250 V AC single-phase — that's the supplementary protector rating for North American panels where the breaker is not the sole branch-circuit overcurrent device.

Frequently asked questions

How do I get current pricing and availability for 5SY6503-7?

Submit an RFQ through this listing. Availability and current pricing are confirmed at quote time through our independent distribution network — we source to order, no minimum commitment.

Will 5SY6503-7 drop into a panel specified around 5SY4101-7CV without rewiring?

Both are 2-pole 1P+N C-curve MCBs on a 36 mm footprint, so mechanical fit is identical. The difference is breaking capacity: 5SY6503-7 carries 30 kA per IEC 60947-2 versus the 5SY4101-7CV's lower rating. If the original panel's fault level exceeds the 5SY4101-7CV's rating, the 5SY6503-7 is a direct upgrade without rewiring.

What compliance documentation does this brand provide for 5SY6503-7?

The breaker is certified to IEC/EN 60898-1, IEC/EN 60947-2, and UL 1077. Construction is halogen-free and silicon-free. Standard documentation includes the declaration of conformity and the datasheet with the full derating curves.
