Siemens 6AG1055-1FB00-7BA2

Siemens 6AG1055-1FB00-7BA2 LOGO! 8 Expansion Module

MPN 6AG1055-1FB00-7BA2
Active

Siemens SIPLUS LOGO! 8 expansion module, 4 digital inputs AC/DC, 4 relay outputs, 115/230 V AC/DC supply, -40 to 70 °C, IP20, 2 SU wide on 35 mm DIN rail.

$348.37 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6AG1055-1FB00-7BA2 specifications
ParameterValue
IP ratingIP20
Depth58 mm
Width35.5 mm
Height90 mm

Product details

Wide-temperature LOGO! 8 I/O slice — what the ratings actually mean for a cold or hot cabinet

The 6AG1055-1FB00-7BA2: That covers unheated outdoor enclosures in northern climates and hot control panels near ovens or solar-exposed walls — the standard LOGO! 8 module typically stops at 55 °C. The cold-restart floor is -25 °C (condensation and frost permitted, though commissioning under condensing conditions is not allowed), so the PLC can power up after a sub-zero night without a heater tape. It provides 4 digital inputs that accept 115 V AC, 230 V AC, 115 V DC, or 230 V DC — the signal-1 threshold is >79 V for both AC and DC, with a typical input current of 0.37 mA at signal-1. The 4 outputs are relay contacts rated 5 A resistive (3 A inductive), so they switch small motor contactors, solenoid valves, or indicator lamps directly without an interposing relay.

Mounting and wiring — panel integration checklist

The 90 mm height and 58 mm depth fit standard 200 mm deep enclosures. Supply voltage range is 100–253 V DC or 47–63 Hz AC, so it runs on any standard single-phase mains or DC bus in that window. The relay outputs are not short-circuit protected — add an external fuse or circuit breaker per output circuit, sized for the 5 A resistive or 3 A inductive limit.
