Siemens SIPLUS HMI MTP1200 Unified Basic Panel, 12-inch widescreen TFT, 16 million colors, touch operation, PROFINET, conformal coating, -20...+50 °C. Based on 6AV2123-3MB32-0AW0.
| Parameter | Value |
|---|---|
| Group code | R141 |
| Product group | 4574 |
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. |
| Series | SIPLUS HMI Unified Basic Panels |
| Export control regulations | AL : N / ECCN : 9N9999 |
| Compliance with the substance restrictions according to RoHS directive | Since: 31-01-25 |
The 6AG1123-3MB32-2AW0: SIPLUS HMI MTP1200 panel for environments that demand conformal coating. 12-inch widescreen TFT display, 16 million colors, touch interface. PROFINET on board. Temperature range -20 to +50 °C covers cold storage or outdoor cabinets. Configurable with WinCC Unified Basic V18 Update 3 or later.
The standard version (6AV2123-3MB32-0AW0) lacks conformal coating and operates 0 to +50 °C. Use the SIPLUS variant when the panel faces condensation, humidity, or subzero startup.
The group code is R141.
The product group is 4574.
The base part 6AV2123-3MB32-0AW0 is the standard version without conformal coating and with a narrower temperature range (0 to +50 °C).
